Disposable Solid Gel ECG Electrodes - Alimosho

This is a disposable foam adhesive electrode measuring 32x40 mm, design to give excellent adhesion and signal transmission, ideal for long-term monitoring

FEATURES:
Simple, comfortable and accurate.

No residual adhesion gel after use.

For use with various ECG devices.

Non-sterile

Foam Backing material protects the sensor and the gel from surgical and cleaning fluid

high quality recordings with minimal skin reactions

Made of Solid Gel which is not only conductive but also adhesive and can be removed without residue


TECHNICAL DATA
PRODUCT
Recomm. Application Monitoring
Characteristics: disposable pregelled, no latex, no PVC, non sterile
Shelf life: 36 months unopened
Storing conditions (min/max): 0° C/ +35° C

CLASSIFICATION AND STANDARDS
Classification (MDD Art. 9) Class I
Classification (21 CFR 870.2360.) Class II

Material
Stud Stainless steel
Backing material: PE-foam
Adhesive: Medical-grade acrylate
Sensor: Silver/silverchloride (Ag/AgCl)
Gel: Solid Gel
Release liner: Siliconized PET- foil (transparent)

BIOCOMPATIBILITY
Test - ISO 10993-1 Backing material (adhesive)

Gel Pass
Cytotoxicity Pass
Skin Irritation Pass
Sensitization Pass



DIMENSIONS
Electrode shape Rectangular
Electrode size - max L/W [cm] 4.1/3.2
Total area [cm²] appr. 13.0
Gel area [cm²] appr. 2.0
Adhesive area [cm²] appr. 10.8
